  • High Quality Professional Horizontal Wood Log Splitter Machine
  • High Quality Professional Horizontal Wood Log Splitter Machine
High Quality Professional Horizontal Wood Log Splitter Machine High Quality Professional Horizontal Wood Log Splitter Machine

High Quality Professional Horizontal Wood Log Splitter Machine

  • Model: WP-1200
  • Worktable: 1200x600mm
  • Power: 15kw
  • Pressure: 40 tons
  • Product description:There are three type of log splitter: vertical type splitter, horizontal type splitter and side type splitter.
  • INQUIRY

Features:

  • The length of the work table has 3 dimension-1000mm, 1200mm and 1500mm.
  • The nominal pressure is 30ton, 40ton, 50ton and so on depend on different model.
  • We can design the splitter with different pressure according to the customers' request.
  • The horizontal type splitter is more convenient to operate. The power can be electric motor or diesel engine depends on customers' need. We also can design it to be mobile type with tires which can be attached to tractor or car.


Advantage:

  • the center of gravity is low so it is steady and safe when working.
  • with more strong power. It can work with materials with big diameter.
  • the hydraulic system is fixed to the main body of the splitter, so it doesn’t need to be installed before use it.
  • Easy to move and transported by simple lifting equipment. And it can be designed to be mobile type with tires attached to tractor or car.


Technical Data:

Model

Work-platform size(mm)

Max. Log Length

(mm)

Max Log Diameter

(mm)

Power

(kw)

Oil cylinder pressure

(tons)

Overall size

(mm)

Weight

(kg)

WP-800

800x600

800

500

7.5

30

2800*600*1100

1200

WP-1000

1000x600

1000

650

11

35

3100*600*1200

1400

WP-1200

1200x600

1200

980

15

40

3400*650*1300

1800

WP-1500

1500x850

1500

1200

18.5

45

4200*1100*1500

2400

how to use log splitter machine
