  • Multifunctional Poultry Feed Grinder Hammer Mill Crusher
  • Multifunctional Poultry Feed Grinder Hammer Mill Crusher
Multifunctional Poultry Feed Grinder Hammer Mill CrusherMultifunctional Poultry Feed Grinder Hammer Mill Crusher

Multifunctional Poultry Feed Grinder Hammer Mill Crusher

  • Model: SFSP-56
  • Rotation Speed: 2950rpm
  • Power: 22kw
  • Capacity: 3-4 t/h
  • Product description:China Factory Agii Brand of Multifunctional Poultry Feed Grinder Hammer Mill Crusher for sale
  • INQUIRY

Main characteristics:


  • The feed hammer mill is widely used in small and medium size feed and food processing industries for raw material grinding.The design of overall is high in structural strength beautiful in appearance.
  • Direct transmission and advanced falk flexible coupling are adopted. The reasonable arrangement of hammers and clearance between hammers and screens make sure the final products are in uniform fineness.
  • Multi-grinding chambers are assembled in this machine. The secondary grinding chamber is cast ironing, which has high abrasive resistance.
  • The bearing imported is with high quality. When working, it has low temperature rising. And it is equipped with the temperature indicator that can show the working condition. The bearing pedestal is SKF brand from Sweden.
  • Various screen/sieve size are selectable. Quick-starting type door opening machinery and frame-type screen pressing mechanism are adopted, which can make the screen fixed solidly and fast to change the new screen, In this way, this design is easy to operate and convenient to maintenance.
  • The tool bit of the hammer is spray welding with long lifetime carbon.

Model

SFSP 56X30

SFSP 56X36

SFSP 56X40

Rotor diameter(mm)

560

560

560

Main shaft rotation speed (rpm)

2950

2950

2950

Hammer's linear speed(m/s)

86

86

86

Crushing chamber width(mm)

300

360

400

Hammer Q’ty(pcs)

16

20

24

Power (kw)

11

22

37

Capacity (t/h)

1-2

3-4

5-6

Dimension(mm)

1400*860*1000

1430*860*1000

1630*860*1000


feed hammer mill crusher
